Technical parameter
1. AC input voltage range:220V or 380V;47-63Hz
2. AC Current THD:<5%
3. Power factor:≥99(@220Vin,pomax)
4. Maximum efficiency:94.0%(@ from 50% to Max load)
5. Noise:≤55dB
6. Grade of waterproof:IP67
7.CAN bus control is optional; Optional low voltage auxiliary 12V,charging lock (charging process can be locked by relay vehiclepower system). CC/CP or PP/Cp canbe added to meet the chargingrequirements of various occasions.
Specification:
| AC input | 1-phase | Unit |
| Input voltage range | 90– 265 | V |
| Input frequency range | 47 – 63 | Hz |
| AC current THD | < 5 | % |
| Power factor | > 0.99 | |
| Efficiency | > 94 @ from 50% to Max load | % |
| Max. input current (eff) | 64 | A |
| Max input power | 13 | kVA |
| INRUSH current | < 40 @ 240 Vac | A |
| DC output | Unit | |
| Voltage programmable range | 400 – 850 | Vdc |
| Min. voltage Constant Power range | 700 | Vdc |
| Charging voltage accurancy | ≤1 | % |
| Charging current accuracy | ≤5 | % |
| Charging current ripple amplitude | ≤1 | % |
| Max. output power | 11 | KW |
| Max. charging current | 18 | Adc |
| Output response time | ≤5 | S |
| Pre-charging | internal |
| Charging function | |
| Charge function | Charging according to BMS communication |
| Communication function | CAN bus control |
| Communication protocol (to BMS) |
By SAE J1939/Defined by customer |
| CAN communication baud rate | 250/500 kbps, without terminate resistor. |
| AC charge control | Compliant SAE J1772 and EN 61851 When SAE J1772 is enabled, the charger is fully compliant with SAE J1772 Power Station (EVSE SAE J1772 compliant, level 1 and 2). When EN 61851 is enabled, the charger is fully compliant with EN 61851 Power Station. |
| Wake-up | 12V signal Hardwire wake up BMS wake-up command CP,CC signal wake up |
